Platform | INTEL® Socket 1700 |
Model Name | AFH610-MI |
Chipset | Intel® H610 |
CPU Supports | Intel® Socket 1200 for Core i7/Core i5/Core i3 Pentium/Celeron Processors Supports Intel 12th / 13th / 14th |
FSB | 2133 / 2400(O.C.) / 2800(O.C.) / 3200(O.C.) / 3800(O.C.) MHz |
Memory | So-Dimm DDR4L 2133 / 2400(O.C.) / 2800(O.C.) / 3200(O.C.) / 3800(O.C.) MHz 1.2V (Memory up to 32GB) |
Dimm | 2 x Memory Slot (Max. up to 32GB) |
Onboard Graphics | Integrated Graphics Processor |
PCI/PCI-E Slots | N/A |
SATA | 2 x SATA2 1 x M.2 (PCIe NVMe Gen3 x4 & SATA3) |
IDE | N/A |
Audio | Realtek 662 on board, supports 6-channel audio-out |
LAN | Realtek RTL8111 1000M lan onboard |
Back Panel I/Os | 1 x HDMI 1 x DP 4 x USB 3.0 1 x LAN 2 x Audio |
ON-Board Pinheaders/Connectors | 1 x USB 2.0 pinheader (support additional 2 USB 2.0s) |
BIOS | UEFI BIOS |
Mounting | 4 mounting holes |
| Form Factor | Mini-ITX (17 x17cm) |
